B-Max 50 kW pellet burner equipment
Low-power burner, designed for civilian buildings. It is equipped with a screw pump for loading.
Bmax Technology burners have an innovative self-cleaning system which works on regular intervals: with this system the fuel grid is periodically freed from possible residue that could interfere with the correct combustion or that could induce the suffocation of the flame. In this way, the possibility of turning off the burner and the consequent dispersion of fumes are avoided.
Safety equipment:
- The B-Max 50 kW pellet burner contain safety equipments:
- Burner safety thermostat (for preventing backfire)
- Cutting valve fire (optional) (for preventing backfire)
Accessories:
- Screw (60 mm)
- Pellet tank (200 kg)
- Compressed air kit
Parts of wood pellet burner:
Description
|
Measurement
|
B-Max 50 kW
|
Burner output
|
kW
|
12÷50
|
Electric connection
|
V~Hz
|
230~50
|
Average energy consumption
|
W
|
60
|
Lighting
|
W
|
170
|
Fuse (delayed)
|
A
|
3,15
|
Noise level
|
dBA
|
40
|
Height of flame
|
mm
|
300
|
Min. combustion chamber (height)
|
mm
|
400
|
Min. combustion chamber (width)
|
mm
|
350
|
Min. combustion chamber (depth)
|
mm
|
450
|
Draught demand
|
Pa
|
20
|
Size and weight of screw feeder:
You can download the detailed description of the B-Max Pellet Burner from here.
